Industrial 10HP Two Stages Belt Type Air Compressor With 270L Tank
- 3m of 4 x 2.5mm² Electric Cable.
- Automatic Pressure Switch.
- Drain valve.
- 1/2" Safety valve.
- 1/4" Exhaust Connector.
- Efficient Iron cover tri-phase electric motor.
- Two stages cast iron air pump (two years guarantee).
10HP Two Stages Belt Type Air Compressors
| Model | Motor | Motor | Voltage | Ampere | Hertz | Speed of Motor | Speed of Pump | Air Inlet | Air Outlet | Air Outlet | Tank Capacity | Working Pressure | Maximum Pressure | Net Weight | Outer Dimension L x W x H |
| HP | Kw | V | A | Hz | R.P.M. | R.P.M. | CFM (L/min) | 90psi (6 bar) | 115psi (8 bar) | liter | Bar | Bar | Kg | mm | |
| LT100NV-100TI-270 | 10 | 7.5 | 380 | 15.8 | 50 | 2900 | 786 | 42.8 cfm (1211 L/min) | 29.1 cfm (823 L/min) | 26.9 cfm (763 L/min) | 270 | 10 | 12 | 249 | 1500 x 525 x 1135 |
