Industrial 10HP Two Stages Belt Type Air Compressor With 270L Tank

Model : LT100NV-100TI-270

Q'ty :

Add To Inquiry

  • 3m of 4 x 2.5mm² Electric Cable.
  • Automatic Pressure Switch.
  • Drain valve.
  • 1/2" Safety valve.
  • 1/4" Exhaust Connector.
  • Efficient Iron cover tri-phase electric motor.
  • Two stages cast iron air pump (two years guarantee).

10HP Two Stages Belt Type Air Compressors

Model Motor Motor Voltage Ampere Hertz Speed of Motor Speed of Pump Air Inlet Air Outlet Air Outlet Tank Capacity Working Pressure Maximum Pressure Net Weight Outer Dimension L x W x H
  HP Kw V A Hz R.P.M. R.P.M. CFM (L/min) 90psi (6 bar) 115psi (8 bar) liter Bar Bar Kg mm
LT100NV-100TI-270 10 7.5 380 15.8 50 2900 786 42.8 cfm (1211 L/min) 29.1 cfm (823 L/min) 26.9 cfm (763 L/min) 270 10 12 249 1500 x 525 x 1135
